| Operating Voltage |
220-240VAC, 50/60Hz, 4.16A, 1.8kW |
| Warm Air Volume Output |
89CFM{151m³/h} |
| Warm Air Temp Output |
65 deg C at ambient T=25 deg C |
| Motor Type |
2800 RPM, 0.1k rpm, Dual Ball Bearings |
| Heater Thermal Protection |
Auto Resetting Thermostat turns unit off at 221 deg F, {105 deg C} |
| Heater Element |
900W @ 220-240VAC, Nichrome 64 |
| Heater Thermal Protection |
Auto resetting Thermostat turns unit off at 85 deg C, Resets at 75 deg C |
| Drying Time |
Less than 30 Seconds |
| Circuit Operation |
Infrared Automatic, Self Adjusting |
| Sensor Range |
4" to 10" [100mm to 250mm], adjustable; standard 6" [17cm±2cm] |
| Timing Protection |
1 minute auto shut off |
| Timing Duration |
10 seconds delayed turn off after last sensor read |
| Sound level |
55.1dB @ 2m |
| Cover Type |
Formed Steel , 1.2mm |
| Cover Finish |
White Epoxy Finish, Bright on stainless steel, satin on stainless Steel |
| Net Weight |
4.6kg |
| Shipping Weight |
5.2kg |
| Unit Size |
250(W) x 361(H) x 146(D)mm |
| RECOMMENDED |
MOUNTING HEIGHTS |
| Men |
50" (1270mm) |
| Women |
47" (1194mm) |
| Children 4-7 Years |
35" (889mm) |
| Children 8-10 Years |
39" (991mm) |
| Children 11-13 Years |
43" (1092mm) |
| Children 14-16 Years |
47" (1194mm) |
| Handicapped |
40" (1016mm) |
